Fluid Power Pumps and Motors: Analysis, Design and Control, 1st Edition

ISBN10: 0071812202
ISBN13: 9780071812207
By Noah D. Manring

© 2013 Published June 26, 2013

ISBN10: 0071812202 | ISBN13: 9780071812207

More information about this Print book can be found in the page section below.

$170.00
ISBN10: 0071812202 | ISBN13: 9780071812207

Print sample not available. Request an eBook sample from the "eBook" tab above.

Step 1. Download Adobe Digital Editions to your PC or Mac desktop/laptop.

Step 2. Register and authorize your Adobe ID (optional). To access your eBook on multiple devices, first create an Adobe ID at account.adobe.com. Then, open Adobe Digital Editions, go to the Help menu, and select "Authorize Computer" to link your Adobe ID.

Step 3. Open Your eBook. Use Adobe Digital Editions to open the file. If the eBook doesn’t open, contact customer service for assistance.

Publisher's Note: Products purchased from Third Party sellers are not guaranteed by the publisher for quality, authenticity, or access to any online entitlements included with the product.


A COMPLETE GUIDE TO FLUID POWER PUMPS AND MOTORS

Written by an expert in the field of fluid power, this book provides proven methods for analyzing, designing, and controlling high-performance axial-piston swash-plate type machinery. Fluid Power Pumps and Motors: Analysis, Design, and Control offers a comprehensive mechanical analysis of hydrostatic machines and presents meticulous design guidelines for machine components. Detailed diagrams and useful formulas are included throughout. Using the results and techniques employed in this practical resource will reduce product delivery lead-time and costs to increase overall efficiency.

COVERAGE INCLUDES:
Fluid properties | Fluid mechanics | Mechanical analysisPiston pressure | Steady-state results | Machine efficiencyDesigning a cylinder block, valve plate, piston, slipper, swash plate, and shaft | Displacement controlled pumpsPressure controlled pumps

Ch 1. Introduction
Typical Machine Applications; General Machine Configuration

Ch 2. Fluid Properties
Fluid Mass-Density; Fluid Bulk-Modulus; Fluid Viscosity; Vapor Pressure; Chemical Properties; Fluid Types & Selection

Ch 3. Fluid Mechanics
Governing Equations; Fluid Flow; Pressure Rise-Rate Equation; Fluid Power; Lubrication Theory

Ch 4. Mechanical Analysis
Cylinder Block Free-Body Diagram; Piston Free-Body Diagram; Slipper Free-Body Diagram; Swash-Plate Free-Body Diagram; Shaft Free-Body Diagram; Kinematics of the Piston-Slipper Joint; Symmetry Considerations; Analytical Results

Ch 5. Piston Pressure
Control-Volume Analysis; Numerical Solutions; Piston-Pressure Profile; Pressure Carry-Over Angle; Cumulative Pressure Effect

Ch 6. Steady-State Results
Cylinder-Block Equations; Piston Equations; Slipper Equations; Swash-Plate Equations; Shaft Equations

Ch 7. Machine Efficiency
Internal Friction; Volumetric Flow Considerations; Pump Efficiency; Motor Efficiency; Typical Results

Ch 8. Designing a Cylinder Block
Cylinder-Block Geometry; Cylinder-Block Materials; Number of Pistons; Cylinder-Block Layout; Involute Spline Design; Cylinder-Block Balance; Cylinder-Block / Valve-Plate Leakage; Cylinder-Block Tipping; Cylinder-Block Filling

Ch 9. Designing a Valve Plate
Valve-Plate Geometry; Valve-Plate Materials; Sizing Valve-Plate Slots; Checking for Cavitation Potential; Line-to-Line Porting; Cross Porting; Trapped Volume Designs; Valve-Plate Indexing; Valve-Plate Clamping

Ch 10. Designing a Piston
Piston Geometry; Piston Materials; Piston Stress & Radial Deflection; Piston-Length Ratios; Miscellaneous Design Practices; Piston Lubrication; Piston Leakage

Ch 11. Designing a Slipper
Slipper Geometry; Slipper Materials; Slipper Stresses; Slipper Design Practices; Slipper Balance; Slipper Leakage; Slipper Tipping; Slipper Hold-Down Devices

Ch 12. Designing a Swash Plate
Swash-Plate Geometry; Swash-Plate Materials; Swash-Plate Stresses; Control & Containment Forces; Swash-Plate Bearings

Ch 13. Designing a Shaft
Shaft Geometry; Shaft Materials; Shaft Deflection; Shaft Stresses; Shaft Bearings

Ch 14. Displacement Controlled Pumps
Pump Description; Analysis; Dynamic Performance; Design

Ch 15. Pressure Controlled Pumps
Pump Description; Analysis; Dynamic Performance; Design

Ch 16. Conclusions
Appendix. Unit Conversions
