Build Your Own Printed Circuit Board
ISBN10: 0071709053
ISBN13: 9780071709057
By Al Williams

Step 1 . Download Adobe Digital Editions to your PC or Mac desktop/laptop.

Step 2. Register and authorize your Adobe ID (optional). To access your eBook on multiple devices, first create an Adobe ID at account.adobe.com. Then, open Adobe Digital Editions, go to the Help menu, and select "Authorize Computer" to link your Adobe ID.

Step 3. Open Your eBook. Use Adobe Digital Editions to open the file. If the eBook doesn’t open, contact customer service for assistance.

Printed circuit boards are at the heart of just about every electronic device made today – PCs, cell phones, MP3 players, PDAs, telephones, stereos, TVs, remote controls, cameras, your car, and even small appliances. The reason these items have come down in price over the years is because of printed circuit boards. Whereas before you had to pay someone to physically connect (and repair!) wires for each component (a time-consuming and thus expensive prospect), now an error-proof, custom “PCB” is installed instead. Hobbyists and designers can now start their projects with a printed circuit board, rather than using it as a last step (and contracting it out to someone else, as was previously the norm). It not only makes a more professional-looking prototype, but also makes it easy to mass-produce. And the techniques are the same for the hobbyist working on a single project.This will be by far the most modern book on the market, with the latest and greatest techniques for producing intricate PCB’s at a fraction of the cost of sending them out.

Chapter 1 PC Board Fundamentals

Chapter 2 Eagle Schematic Capture

Chapter 3 Board Layout

Chapter 4 Auto Routing

Chapter 5 Custom Libraries

Chapter 6 Scripting and Programming

Chapter 7 Eagle Output

Chapter 8 Boards from a Laser Printer

Chapter 9 Photographic Boards

Chapter 10 Outsourcing Boards

Chapter 11 End to End

Chapter 12 More Choices

APPENDIX

INDEX
